TOPONE Segment Wheels are designed for bushing-chain and plate-conveyor systems. The catalogue shows segment wheels as individual components and as part of complete driving group assemblies. Available examples include a Z=15 segment wheel, a sixfold wheel with a 3-inch pitch and 197 teeth, and special wheel segments. Segment dimensions, number of rows, tooth count and driving-group configuration are determined according to the conveyor design. The reference catalogue does not provide a standard dimensional table for this product.
Segment Wheels consist of multiple wheel sectors assembled around a wheel body or driving group. The catalogue presents these wheels as components for plate conveyors and bushing-chain systems.
The product examples shown in the catalogue include:
Segment Wheel Z=15;
Sixfold wheel with 3-inch pitch and 197 teeth;
Special segments;
Segment wheels for plate conveyors;
Driving group assemblies;
Prepared materials for wheel production.
Segment Wheels can be supplied as wheel components or incorporated into a complete driving group. The required number of teeth, number of wheel rows, segment design and assembly arrangement must correspond to the conveyor configuration.
| Parameter | Catalogue Information |
| Product name | Segment Wheels |
| Product category | Wheels for bushing chains |
| Catalogue example | Segment Wheel Z=15 |
| Number of teeth in example | 15 |
| Multiple-wheel example | Sixfold Wheel |
| Multiple-wheel pitch | 3 inches |
| Multiple-wheel tooth count | 197 |
| Related components | Special Segments |
| Conveyor type shown | Plate Conveyor |
| Assembly shown | Driving Group Assembly |
| Manufacturing item shown | Prepared Material |
| Dimensional specifications | Not specified in the reference catalogue |
| Other configurations | To Be Confirmed |
Name: Segment Wheels
MOQ: 1 Piece
Package: Carton + Steel Pallet
Manufacturing Standards:
The reference catalogue does not specify separate manufacturing standards, materials, heat-treatment requirements or dimensional tolerances for Segment Wheels. Manufacturing requirements shall follow the confirmed conveyor drawings, wheel configuration, segment design, tooth count and driving-group arrangement.
Testing Standards:
The reference catalogue does not specify separate testing standards. Product dimensions, segment assembly, tooth arrangement and driving-group configuration shall correspond to the approved technical drawings.
Application Standards:
The reference catalogue does not specify separate application standards.
Maintenance Standards:
The reference catalogue does not specify separate maintenance standards or inspection intervals for Segment Wheels.
