Grade 100 Eye Sling Hook w/ LatchDesigned to be attached directly to a length of chain via a connecting linkGrade 100 alloy steelIncrease in working load limit by at least 25% as compared to a similar product in Grade 80Tough powder coat finishHeavy duty forged latch with springReplacement parts always availableProof tested and certified
| FOR CHAIN (in) | A (in) | A1 (in) | D (in) | G (in) | H (in) | O (in) | R (in) | WORKING LOAD LIMIT | WEIGHT (lbs) |
| 7/32-1/4 | 1.02 | 0.75 | 0.39 | 0.63 | 0.79 | 0.81 | 3.19 | 3,000 | 0.55 |
| 9/32-5/16 | 1.30 | 1.02 | 0.43 | 0.75 | 1.14 | 0.98 | 3.98 | 5,700 | 1.10 |
| 3/8 | 1.57 | 1.22 | 0.63 | 1.02 | 1.30 | 1.34 | 5.16 | 8,800 | 2.14 |
| 1/2 | 2.01 | 1.57 | 0.75 | 1.30 | 1.65 | 1.69 | 6.26 | 15,000 | 4.19 |
| 5/8 | 2.20 | 1.77 | 0.96 | 1.57 | 1.97 | 1.97 | 7.20 | 22,600 | 7.28 |
| 3/4 | 2.36 | 2.05 | 1.08 | 1.89 | 2.09 | 2.17 | 7.99 | 35,300 | 9.92 |
| 7/8 | 2.78 | 2.44 | 1.14 | 1.97 | 2.36 | 2.36 | 8.82 | 42,700 | 15.65 |
| 1 | 3.03 | 2.87 | 1.38 | 2.36 | 2.95 | 2.76 | 10.12 | 59,700 | 26.46 |
| 1-1/4 | 4.02 | 3.82 | 1.62 | 2.87 | 3.58 | 3.31 | 13.19 | 90,400 | 59.52 |
Name: Grade 100 Eye Sling Hook w/ Latch
Package: Carton + Steel Pallet
