Grade 100 Clevis Self Locking (Safety) HookThe latch on this hook automatically closes when pulling force is applied to the slingDesigned to attach directly to a length of chain via the engineered clevis headThis engineered head prevents hook to chain mismatchGrade 100 Alloy SteelIncrease in working load limit by at least 25% as compared to a similar product in Grade 80Tough powder coat finishReplacement parts always availableProof tested and certified
| FOR CHAIN | A | B | C | G | H | R | T | PxL | Weight (lbs) | WORKING LOAD LIMIT |
| 7/32 | 1.10 | 0.28 | 0.31 | 0.63 | 0.83 | 3.70 | 1.38 | 0.30×0.69 | 1.1 | 3,000 |
| 9/32 | 1.34 | 0.35 | 0.39 | 0.79 | 1.02 | 4.84 | 1.69 | 0.35×0.89 | 2.09 | 4,300 |
| 5/16 | 1.34 | 0.35 | 0.39 | 0.79 | 1.02 | 4.84 | 1.69 | 0.39×0.89 | 2.09 | 5,700 |
| 3/8 | 1.77 | 0.47 | 0.55 | 0.98 | 1.18 | 5.63 | 2.20 | 0.51×1.24 | 3.53 | 8,800 |
| 1/2 | 2.01 | 0.59 | 0.67 | 1.38 | 1.57 | 7.09 | 2.72 | 0.63×1.65 | 7.05 | 15,000 |
| 5/8 | 2.36 | 0.75 | 0.75 | 1.42 | 1.97 | 8.46 | 3.15 | 0.83×2.03 | 13.23 | 22,600 |
| 3/4 | 2.76 | 0.91 | 1.02 | 2.36 | 2.64 | 9.96 | 3.54 | 0.94×2.87 | 21.61 | 35,300 |
| 7/8 | 3.23 | 1.02 | 1.26 | 2.44 | 2.76 | 11.30 | 3.94 | 1.02×2.83 | 31.75 | 42,700 |
Name: Grade 100 Clevis Self Locking (Safety) Hook
Package: Carton + Steel Pallet
