| LINK SPECIFICATION | TEST LOAD | BREAKING LOAD | NETWT PER 200FT(KG) | ||||
| D | L | W | |||||
| IN | MM | MM | MM | KG | KG | B.F. | H.D.G. |
| 1/8 | 3.2 | 16 | 12 | 200 | 400 | 11.4 | 11.74 |
| 5/32 | 4 | 18.5 | 14.5 | 300 | 600 | 18.6 | 19 |
| 3/16 | 4.7 | 19 | 17 | 400 | 800 | 26.2 | 27 |
| 7/32 | 5.5 | 20 | 19 | 550 | 1100 | 36.8 | 38 |
| 1/4 | 6.35 | 22 | 21 | 750 | 1500 | 50 | 51.5 |
| 5/16 | 7.94 | 26 | 26 | 1200 | 2400 | 80 | 82.4 |
| 3/8 | 9.5 | 28 | 32 | 1700 | 3400 | 122 | 125.7 |
| 7/16 | 11.11 | 33 | 36 | 2300 | 4600 | 164 | 169 |
| 1/2 | 12.7 | 39 | 43 | 3000 | 6000 | 210 | 216 |
| 5/8 | 15.8 | 45 | 53 | 4700 | 9400 | 334 | 344 |
| 3/4 | 19 | 55 | 63 | 6800 | 13600 | 485 | 499 |
| 7/8 | 22.2 | 64 | 74 | 9250 | 18500 | 656 | 675 |
| 1 | 25.4 | 73 | 84 | 12150 | 24300 | 870 | 896 |
